Savox

SA1230SG - DISCONTINUED - Please See SA1230SGP for Replacement

$88.99$109.99
  • SAVSA1230SG-Coreless-Digital-Servo
  • SAVSA1230SG-Coreless-Digital-Servo
  • SA1230SG - DISCONTINUED - Please See SA1230SGP for Replacement

Savox

SA1230SG - DISCONTINUED - Please See SA1230SGP for Replacement

$88.99$109.99

Description

DISCONTINUED, PLEASE CLICK HERE FOR REPLACMENT!

The Savox SA-1230SG Monster Torque Steel-Gear digital servo is the servo that is ideal for those requiring extra torque, but not using high voltage as a power source.
Features:

  • Extremely strong unique steel gears ensure long-life and durability.
  • Ideal for steering on rock crawlers, monster trucks, and large scale aircraft.
  • Slightly taller case design.

  • Specifications:
  • Torque @ 4.8v - 30.0kg/416.6oz-in
  • Torque @ 6v - 36.0kg/499.9oz-in
  • Speed @ 4.8v - 0.20 sec/60 deg
  • Speed @ 6v - 0.16 sec/60 deg
  • Dimensions L x W x H (mm): 40.3 x 20.2 x 44.9
  • Weight: 79.0g
  • Technical Details

  • Operating Temperature: 14° - 122°F (-10° - 50°C)
  • Running Current (no load): 180mA @4.8V, 250mA @6.0V
  • Stall Current (at locked): 4200mA @4.8V, 5300mA @6.0V
  • Idle Current: 5mA @4.8V, 5mA @6.0V
  • Wire Length: 200 +/- 5mm
  • Output Gear Spline: 25 Tooth
  • Bearings: 2BB
  • Operating Travel: 100° (1000 → 2000 µ second)
  • Neutral Position: 1500 µ second
  • Pulse Width Range: 800 → 2200 µ second
  • Maximum Travel: Appx 130° (900 → 2100 µ second)
  • Refresh Rate: 333 Hz
  • Motor Type: Coreless
  • 1 Year Warranty

    Savox servos are backed with a warranty for 1 year after purchase (see warranty page for details)
