Savox

SA1283SG - DISCONTINUED - Please See SA1283SGP for Replacement

$107.99$133.99
  • SAVSA1283SG-Coreless-Metal-Case-Digital
  • SAVSA1283SG-Coreless-Metal-Case-Digital
  • SA1283SG - DISCONTINUED - Please See SA1283SGP for Replacement

Savox

SA1283SG - DISCONTINUED - Please See SA1283SGP for Replacement

$107.99$133.99

Description

DISCONTINUED, PLEASE CLICK HERE FOR REPLACMENT!

The SA1283SG combines leading-edge technology with high 12-bit (4096) resolution for one amazing servo! The strong unique steel gears and all aluminum case ensure long-life and durability.

Features:

  • Combines leading edge technology with super high 12 bit (4096) resolution.
  • Extremely strong unique steel gears ensure long-life and durability.
  • Full aluminum case design provides for durability.
  • Ideal for steering on rock crawlers, monster trucks, and 1/8th scale vehicles.

  • Specifications:
  • Torque @ 4.8v - 25.0kg/347.2oz-in
  • Torque @ 6v - 30.0kg/416.67oz-in
  • Speed @ 4.8v - 0.16 sec/60 deg
  • Speed @ 6v - 0.13 sec/60 deg
  • Dimensions L x W x H (mm): 40.3 x 20.2 x 36.4
  • Weight: 80.0g
  • Technical Details

  • Operating Temperature: 14° - 122°F (-10° - 50°C)
  • Running Current (no load): 100mA @4.8V, 120mA @6.0V
  • Stall Current (at locked): 4800mA @4.8V, 6000mA @6.0V
  • Idle Current: 5mA @4.8V, 5mA @6.0V
  • Wire Length: 300 +/- 5mm
  • Output Gear Spline: 25 Tooth
  • Bearings: 2BB
  • Operating Travel: 90° (1000 → 2000 µ second)
  • Neutral Position: 1500 µ second
  • Pulse Width Range: 950 → 2050 µ second
  • Maximum Travel: Appx 130° (900 → 2100 µ second)
  • Refresh Rate: 333 Hz
  • Motor Type: Coreless
  • 1 Year Warranty
